Compact LED switching power supplies by SELF Electronics - the right decision for every situation.


• independent power supply
• class II protection, SELV output
• constant current and constant voltage
• IP 20
• protected against over load, short circuit, over voltage and over temperature
• EN61347-1, EN61347-2-13, EN55015, EN61000-3-2, etc.
• for LED lighting applications

SNT IP20 6 W 3-9 V / 0,7 A CV+CC

• General
• • Type
  • LED transformer
  • Technology
  • Constant current + constant voltage
  • Input
  • 220 - 240 V AC
  • Output
  • 13 V DC
  • Temperature monitoring
  • Yes
  • Colour
  • White

• Electrical values
• • Current
  • 0.7
  • Voltage
  • 3 - 9 DC V
  • Performance
  • 6 W
  • Efficiency
  • 74.5 %
  • Inrush
  • 7 A

• Specials
• • Overload protection
  • Yes
  • Short circuit protected
  • Yes

• Implementation
• • Surge protection
  • Yes
  • Protection class
  • IP20

• Measures
• • Length
  • 68 mm
  • Width
  • 35 mm
  • Height
  • 20 mm

• Power supply
• • Mains voltage input
  • 198 - 264 V AC
  • Mains frequency
  • 50/60 Hz
  • Power supply, on device
  • Terminals
  • Output voltage, connection
  • Terminals
